Factory Price Trailer Disc
Factory Price Trailer Disc Brake Axle Shaft For Semi Trailer
2023-02-07
China Manufacture Disc
China Manufacture Disc Brake Axle Shaft Heavy Duty Truck Trailer
2023-02-07

Trailer Disc Brake Axle Trailer Axle With Disc Brake From Factory Sale

Trailer Disc Brake Axle
Trailer Disc Brake Axle

Product Introduction Of Trailer Disc Brake Axle

Technical Parameter of Trailer Disc Brake Axle

Model

Axle Beam(mm)

Capacity(kg/lbs)

Spring canter(mm)

Track

LHU2009DB001A

127

9/20

980

1835

LHP20DB01AA12

127

11.5/25

980

1850

LHP24DB01AA30

127

13/29

980

1850

 Noted:

  1. The  Trailer Disc Brake Axle can be customized according to customer requirements
  2. Axles can install ABS brake.
  3. Axles can install Air brake chamber

Detailed Images of Trailer Disc Brake Axle

Disc-3
Disc Brake Shaft Axle
Trailer Disc Brake Axle
Disc Brake Shaft Axle
Trailer Disc Brake Axle

Product Features of Trailer Disc Brake Axle

  1. Shaft body advantage: the shaft tube is made of high quality alloy steel by special technology, high strength, light weight, good coaxiality of both ends of the tube body.
  2. Brake advantage: the brake shoe seat is finished in one time by six-hole boring machine, high processing volume, high positioning accuracy, asbestos-free friction plate, in line with international environmental protection standards.
  3. S-type cam head design and adjustable brake chamber sub-pump hole make its braking force larger, and it can more reasonably distribute the front, rear and rear axle braking forces, and the braking force distribution is more reasonable.
    The special formula shoe used has a large friction coefficient, high temperature resistance, better braking performance, and long-distance braking can also operate freely, which can shorten the braking distance.

Production Process of Trailer Disc Brake Axle

Raw Materials
Cutting Pipe
Plate Cutting
Machining
Welding
Shot Blasting
Painting
Assembiy
Finished Products

Package of Trailer Disc Brake Axle

Normally, we packing our goods with wooden cases.

  1. Standard export package (from inside to outside): oiled paper, boxes, cartons, (and wooden pallets).
  2. Protective packaging for specific parts:
    The wheels are packed in highly elastic pearl cotton to prevent collisions during transport.
    The bolts and caps have a protective sleeve of their own.
    The wheels are wrapped in stretch film to prevent damage.
packing

FAQ of Trailer Disc Brake Axle
